Electronics
Motor
Mivice M070 Rear Hub Motor (250W Power, 40 Nm Max. Torque)
Battery
36V, 10.4Ah Lithium-ion Battery with 18650 cells
Display
Integrated Smart LCD Display
Sensor
Mivice S200B Torque Sensor
Controller
Mivice C201 Controller
Lights
StVZO-compliant
Performance
Top Speed
25 km/h*
*The motor will stop giving assist at the stated top speed. You can still ride beyond the stated top speed with pure muscle power. This limit is set in accordance with local regulations.
Range
Up to 100 km*
*Actual performance will vary depending on temperature, road conditions, rider's weight, etc.
Climbing Ability
Suitable for flat roads*
*The actual performance would depend on the rider's physical strength.
Component
Frame
6061 Aluminium Frame
Front Fork
SR SUNTOUR Suspension Front Fork
Crankset
Gates CDX Crankset
Drivetrain
Single-speed Drivetrain
Gates CDN Carbon Belt
Tires
CST Puncture-proof 700*48C size Tires
Bottom Bracket
Fully-concealed Bottom Bracket
Wheels
28" Aluminium Rims
Brake
TEKTRO Hydraulic Disc Brakes
Weight*
Net weight: 19 kg (excluding all accessories)
Full weight: 23 kg (including all accessories)
Permissible Max. Weight: 145 kg*All stated weight numbers have a +/- 3%-5% tolerance. Net weight includes the battery but excludes all accessories. Full weight includes the battery and all accessories.
*Specifications are subject to change without notice. In case of unexpected supply-side impacts, we will offer components of equivalent or better capabilities.
Geometry
| One Size (mm) | SYMBOL | |
| Effective top tube | A | 600 |
| Seat tube length | B | 480 |
| Head tube | C | 190 |
| Steering angle | D | 71 |
| Seat tube angle | E | 73 |
| Chainstay | F | 457 |
| Wheelbase | G | 1103 |
| Standover | H | 430 |
